Kev piav qhia
E94, E95, E96 yog series ntawm thermal Circuit Court breakers uas tsim los ntawm ntau lub tuam txhab thiab feem ntau siv hauv kev siv hluav taws xob thiab hluav taws xob. Lawv paub txog lawv qhov pib-rov pib dua thiab phau ntawv rov pib dua nta, uas muab kev tiv thaiv overcurrent rau cov khoom rhiab thiab circuits.
E94 Circuit Breaker
E94 Circuit Court breakers yog feem ntau pib pib dua Circuit Court breakers. Thaum muaj xwm txheej overcurrent tshwm sim, xws li ib tug luv luv Circuit Court los yog overloading, lub breaker yuav tawm mus thiab disconnect lub Circuit Court. Tom qab lub sijhawm txias-tawm luv luv, lub breaker yuav rov pib dua nws tus kheej thiab tso cai rau cov dej ntws rov qab. Qhov kev rov pib dua tsis siv neeg no ua rau E94 Circuit Court breakers tsim nyog rau cov ntawv thov uas yuav tsum muaj overloads ib ntus.
E95 Circuit Breaker
E95 Circuit Court breakers yog phau ntawv rov pib dua Circuit Court breakers. Thaum tus mob overcurrent ua rau lub breaker, nws disconnects lub Circuit Court thiab tseem nyob rau hauv lub tripped txoj hauj lwm kom txog rau thaum manually pib dua los ntawm tus neeg siv. Qhov kev hloov pauv ntawm phau ntawv no yuav tsum ua kom ntseeg tau tias qhov hluav taws xob tseem raug kaw kom txog thaum tus neeg siv cuam tshuam, uas tuaj yeem ua rau muaj kev nyab xeeb hauv qee daim ntawv thov.
E96 Circuit Breaker
E96 Circuit Court breakers yog ib qho kev hloov pauv uas tuaj yeem muab ob qho tib si pib pib dua thiab phau ntawv rov pib dua kev xaiv hauv ib lub cuab yeej. Cov breakers no feem ntau muaj lub laub-khawm lossis toggle hloov uas tso cai rau tus neeg siv xaiv ntawm nws pib rov pib dua thiab phau ntawv pib dua hom. Hauv hom pib pib dua, lawv ua haujlwm zoo li E94 breakers, rov pib dua tom qab tripping. Nyob rau hauv phau ntawv-reset hom, lawv coj zoo li E95 breakers, yuav tsum tau phau ntawv cuam tshuam los pib dua.
Parameter
| Khoom npe: | E94 E95 E96 HI AMP Marine Circuit Breaker | Pib dua hom: | Phau ntawv rov pib dua |
|
Rated voltage: |
DC 12-48V | Rated Tam sim no: | 25A-250A |
| Kho vajtse: | Zinc Alloy | Khoom siv: | Yas thiab Hlau |
| Ncej: | Tib Ncej | Hom: | Thermal Circuit Breaker |
| Interrupt Capacity: | 2,500A ntawm 14Vdc / 1,500A ntawm 48Vdc | Kev ntsuas kub ua haujlwm: | -25 degree F (-32 degree) txog 180 degree F (82 degree) |
| Ingress Protection Rating: | ip67 ua | Cia Temperature Rating: | -34ºC (-30ºF) txog 149ºC (300ºF) |
| Mounting: | Nto mounting | Ntim: | Lub hnab npuas |
Paub meej
Daim ntawv thov
E94, E95, thiab E96 Circuit Court breakers muaj ntau yam kev siv hauv ntau yam lag luam uas tsim nyog tiv thaiv overcurrent. Lawv daim ntawv thov tshwj xeeb yuav nyob ntawm hom (pib pib dua, phau ntawv rov pib dua, lossis dual-hom) thiab lawv cov yam ntxwv hluav taws xob. Nov yog qee qhov kev siv rau cov hom kev sib txuas hluav taws xob no:
1. Automotive Applications:Cov hluav taws xob hluav taws xob no yog siv hauv tsheb los tiv thaiv ntau yam hluav taws xob hluav taws xob, xws li teeb pom kev zoo, lub cev muaj zog, thiab cov khoom siv ntxiv. Nws pib-reset Circuit Court breakers (E94) tuaj yeem siv los tiv thaiv circuits uas yuav muaj kev overloads ib ntus, thaum phau ntawv rov pib dua (E95) breakers tuaj yeem siv rau qhov tseem ceeb xws li lub cav tswj lub cav (ECU).
2. Cov khoom siv hluav taws xob thiab khoom siv:E94 Circuit Court breakers feem ntau pom muaj nyob rau hauv cov neeg siv khoom siv hluav taws xob thiab cov khoom siv hluav taws xob uas muaj kev cuam tshuam ib ntus tuaj yeem tshwm sim. Piv txwv li, lawv yuav siv tau rau hauv cov khoom tiv thaiv hluav taws xob, lub zog hluav taws xob, lossis cov khoom siv hluav taws xob hauv computer. E95 Circuit Court breakers tuaj yeem siv rau hauv cov khoom siv uas yuav tsum tau muaj kev cuam tshuam los ntawm phau ntawv kom rov pib dua tom qab ua txhaum.
3. Muaj Machinery:Cov kab hluav taws xob hluav taws xob no tuaj yeem siv rau hauv cov cuab yeej siv thiab tshuab los tiv thaiv lub cev muaj zog, tswj Circuit Court, thiab lwm yam khoom siv hluav taws xob. Nws pib-reset versions yog tsim rau cov tsis tseem ceeb circuits, thaum phau ntawv-reset versions yuav siv tau rau kev ruaj ntseg circuits tseem ceeb uas yuav tsum tau nyob twj ywm kom txog thaum manually pib dua.
4. Marine thiab Recreational Vehicles:E94 thiab E95 Circuit Court breakers feem ntau yog siv hauv nkoj thiab tsheb ua si los tiv thaiv ntau lub tshuab hluav taws xob, suav nrog teeb pom kev zoo, twj, thiab cov khoom siv hluav taws xob.
5. Aerospace thiab Aviation:Hauv dav hlau thiab dav hlau, cov hluav taws xob hluav taws xob tau siv los tiv thaiv cov tshuab thiab cov khoom siv tseem ceeb. Qhov kev xaiv ntawm nws pib-reset thiab phau ntawv-reset versions nyob ntawm daim ntawv thov tshwj xeeb thiab kev ruaj ntseg yuav tsum tau.
Cov ntaub ntawv Hoobkas
Dongguan Senreach Electronics Co., Ltd, nrhiav tau nyob rau hauv 2011, yog ib tug kws tshaj lij Circuit Court tiv thaiv Cheebtsam chaw tsim tshuaj paus thiab cov kev pab cuam nyob rau hauv Suav teb. Peb muaj 20 xyoo kev paub hauv kev tsim fuse, fuse tuav, Circuit Court breaker, thermal protector, ntc sensor thiab lwm yam.
Nrog rau ntau yam kev tsim khoom thiab kev sim cov cuab yeej zoo tshaj plaws, peb tshaj tawm cov kev tswj xyuas zoo tshaj plaws kom ntseeg tau tias txhua daim ntawm peb cov khoom muaj kev nyab xeeb thiab ruaj khov. Peb cov haujlwm yog ISO9001:2000- ntawv pov thawj thiab cov khoom ua tau raws li cov qauv thoob ntiaj teb.
Peb tau tshwj xeeb hauv kev tsim, tsim thiab muag cov khoom tiv thaiv hluav taws xob rau kev siv tam sim no, dhau-kub thiab dhau-voltage daim ntaub ntawv nrog rau cov kev ua tau zoo, hom thiab specifications. Peb cov khoom siv dav siv hauv cov neeg siv khoom siv hluav taws xob, tsheb, nkoj, kev sib txuas lus, khoom siv hluav taws xob, lub zog tshiab, photovoltaic thiab lwm yam.
Rhiav
Rhiav
Rhiav
Rhiav
Rhiav
Rhiav
Rhiav
Rhiav
vim li cas xaiv peb
Nqe Advantage
Peb tsim peb cov pwm thiab muaj peb tus kheej lub Hoobkas uas ua rau peb muab tus nqi thawj zaug rau peb cov neeg siv khoom. Thiab peb tau mob siab rau txo tus nqi tsim khoom thiab muab tus nqi zoo tshaj plaws txhua xyoo.
Guaranteed Zoo
Txhua daim ntawm cov khoom dhau los ntawm kev soj ntsuam tag nrho los ntawm ob qho tib si pib kuaj cov cuab yeej thiab peb pab pawg QA.
Factory wholesale
Rau qee cov khoom kub muag, peb muaj cov khoom hauv tsev thiab tuaj yeem npaj xa khoom hauv 1 lub lis piam. Thiab rau lwm yam khoom, lub sijhawm ua khoom siv yog 2-4 lub lis piam.
Ib-Qhov rai kev pabcuam
Peb muaj ib pab neeg muaj zog thiab ua tiav nrog rau R & D, kev muag khoom, QC, PMC, warehouse thiab CS kom paub tseeb tias peb tuaj yeem pab tau peb cov neeg siv khoom zoo dua.
Peb daim ntawv pov thawj
kev ua yeeb yam
